QCP1.53 All-in one
Chee Chuang
8528591090
Product Description
P1.53 indoor All-in-one led display 116" is typically used in shopping mall, meeting room, shops, store, airport, hotel, cinema, home, expo center. It works under Android system, supports four scene modes: standard, soft, cinema, and video, it can also play TV programs.
1.The All-in-one LED screen is the new generation seamless led screen that was born for medium and big.
2. With a high refresh rate, high contrast, broad color performance,and dynamic picture quality, it creates excellent visual experiences that any other type of TV can't compete with.
3. Android system and Wifi/bluetooth interconnected make easy operating.
Technical Parameters
P1.53 indoor All-in-one led display 116" | |
Pitch Size | P1.53 |
Pixel Configuration | 1 Red, 1 Green, 1 Blue SMD1212 |
Module Size | 320*160mm |
Module Pixel(dots) | 208dots*104dots |
Screen size | 2560mm*1440mm |
Screen resolution | 1664*936dots |
View angle(H/V) | ≥160/120degree |
Brightness | ≥700cd/m2 |
Drive mode | constant current driving, 1/52 scan |
View distance | 3--20m |
Average Power consumption | 360W/m2 |
Net weight | 100kg/m2 |
Operating temperature | —25°C~+60°C |
Operating humidity | 10%—95%RH |
Exchange frame speed | >150frames per second |
Refresh frame frequency | 3840Hz |
Power | 110V/220V±15% 50Hz/60Hz |
Operating system | Android system |
Protection Level | IP31 |
Maintenance way | front access |
Function | Support wireless screen projection on multi terminals |
Supports local, wireless HD video playing | |
Dual WIFI mode | |
Supports four scene modes: standard, soft, cinema, and video | |
Product Uses
P1.53 indoor All-in-one led display 116" is typically shopping mall, meeting room, shops, store, airport, hotel, cinema, home, expo center.
Company Profile
FAQ
Q1: What pixel pitch and screen size should I choose on my display?
A:Using the PX screen, it is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.
Q2: To order a display ,What kind of information do I have to offer you?
A:You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements,then I can provide you with a detailed list of quotations.
Q3: What about the lead time?
A:Orders less than 50m2, lead time is 15 working days.
Q4: How many years warranty?
A:2-3 years warranty, any quality problem during warranty time will be handled .
Q5. Can I get prompt service?
A: Any inquires will be replied within 24/7 hours and you'll get helpful suggestions from us.
Q6:Can I order a sample?
A:Yes, your sample orders are welcome, after checking our quality and service, we are confident that you will come back for your future orders.
