Waterproof P10 outdoor led screen electronic big digital billboard advertising display

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Description

Features of outdoor led display

P10 full color led display screen is a type of LED display device that can be installed outdoors. It is based on complex technology systems such as microcontroller, LED display technology, multimedia technology, etc.

It is a long-distance communication medium with high brightness, good transmittance, high clarity, high refresh rate, diverse installation forms, obvious visual effects, easy maintenance, and long service life. It is generally used for propaganda, commercial advertising, stations, and other occasions.

Product Advantage

1、 Outdoor led screen have waterproof properties, strong UV resistance, and a protection level of IP65 or above, which can cope with various adverse weather conditions, such as strong winds and heavy rain

2、Outdoor Waterproof Advertising LED Display can provide a variety of installation forms according to the installation environment and user's actual requirements, such as horizontal installation, sloping roof installation, column installation, etc., and can be installed anywhere.

3、 Long lifespan: Under appropriate current and voltage usage, the lifespan of LED can reach 100000 hours.

4、 Easy to interface with computers, rich software support, and direct access to standard video signals, audio signals, and other network devices, with strong compatibility. Automatic selection of broadcasting equipment through programming, achieving unmanned broadcasting

5、 Green and environmentally friendly, led video wall is mainly composed of LED lamp beads, which are made of non-toxic materials. And LED power consumption is quite low, generally speaking, the working voltage of LED is 2-3.6V. The working current is 0.02-0.03A. This means that it consumes no more than 0.1W of electrical energy.

6、Outdoor advertising digital led screen have high brightness, with a general brightness of 5500cd. They have ultra-high definition image quality effects outdoors, and can be clearly visible even under strong light, resulting in good display effects.

Technical Parameters

Pitch Size


Module Size


Module Pixel(dots)


Pixel Configuration

1 Red, 1 Green, 1 Blue SMD 3-in-1

Color scale


Pixel density

10000pixels/square meter

View angle(H/V)



≥5500cd/square meter

Brightness adjustment

64 level automatic or manual

Power consumption

100-1200W/square meter

Net weight

40kg/square meter

Operating temperature


Operating humidity


Life time


Out of control dot


Whole Display Flatness

≤1mm Juncture

Exchange frame speed

>150frames per second

Refresh frame frequency


Control distance

120m (without repeater), single mode fiber:20km, multi mode fiber: 500m


110V/220V±15% 50Hz/60Hz

Operating system

Windows series

Drive mode

constant current driving, 1/4 scan

Display mode


Protection Level


Maintenance way

Rear access

Accepting signal

PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

Product Uses

Advertising led display are widely used in outdoor commercial advertising, mainly for outdoor advertising, stations, squares, shopping malls, etc.

1. Advertising field: outdoor billboards, billboard stations, large advertising display areas, etc.

2. Commercial center: advertising and promotion of shopping malls, shopping centers, commercial streets, etc.

3. Entertainment venues: outdoor cinemas, concerts, sports events, entertainment venues, etc.

4. Transportation: Timetables and information for bus stop signs, subway stop signs, train stations, airports, etc

Display, advertising, etc.

5. Building exterior walls: Advertising and publicity for large building exterior walls, commercial building exterior walls, etc.

6. Urban roads: road condition information, driving safety tips, public welfare promotion, etc.

Company Profile

Qichuang was founded in 2005 and is one of the largest and most professional LED display manufacturer in Guangzhou.Our company is an integrated service provider in the LED display industry,offering mainly turnkey solutions to customers on LED display applications.

Qichuang achieves ISO9001, CE, ROHS, FCC, CCC. CB certificates. With features of stability,high resolution, vivid color,long life-span, power saving and cost saving. We have high reputation among domestic and overseas customers.

Qichuang Exported to 83+countries and regions such as USA, Canada, Mexico, Guatemala, Italy , Germany France, Poland, Russia, Qatar, UAE, Lebanon, Saudi, Arabia, Brazil, Argentina, Thailand, Indonesia. Nigeria, Ethiopia,South Africa,etc.

Qichuang LED displays are shining in outdoor advertising bilboards/ business centers/ shopping malls/sport stadiums /indoor &outdoor stages/ exhibitions/ TV stations/ traffic signs and so on.


1.How can I get the price?

-We usually quote within 24 hours after we get your inquiry(Except weekend and holidays).

-If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.

2. Can I buy samples placing orders?

-Yes.Please feel free to contact us.

3.What is your lead time?

-It depends on the order quantity and the season you place the order.

4.What is your payment term?

-T/T,Western Union,and L/C.This is negotiable.

5.What is the shipping method?

-It could be shipped by sea.Please confirm with us before placing orders.

6.How about your warranty?

-Our warranty is 2 years, and in addition, we will have a professional after-sales service team online to answer your questions.
