HD P10 Outdoor Waterproof Advertising Led Display

P10 outdoor full color LED display screen, with a point spacing of 10mm and 10000 points/square meter, high refresh rate, waterproof and sunscreen, recommended viewing distance of 15 meters or more, and screen area of 80 square meters or more, for use in schools, squares, street advertisements, and other places
  • P10

  • Chee Chuang

  • 8528591090

Size:
Material:
Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

product details

HD P10 Outdoor Waterproof  Advertising Led Display


Features of outdoor led display

P10 full color led display screen is a type of LED display device that can be installed outdoors. It is based on complex technology systems such as microcontroller, LED display technology, multimedia technology, etc.

It is a long-distance communication medium with high brightness, good transmittance, high clarity, high refresh rate, diverse installation forms, obvious visual effects, easy maintenance, and long service life. It is generally used for propaganda, commercial advertising, stations, and other occasions.



Product Advantage


1、 Outdoor led screen have waterproof properties, strong UV resistance, and a protection level of IP65 or above, which can cope with various adverse weather conditions, such as strong winds and heavy rain

2、Outdoor Waterproof Advertising LED Display can provide a variety of installation forms according to the installation environment and user's actual requirements, such as horizontal installation, sloping roof installation, column installation, etc., and can be installed anywhere.

3 、Easy to interface with computers, rich software support, and direct access to standard video signals, audio signals, and other network devices, with strong compatibility. Automatic selection of broadcasting equipment through programming, achieving unmanned broadcasting



4


5


Technical Parameters

Pitch Size
10mm
Pixel density
10000pixels/square meter
Module size
320*160mm
Cabinet size
960*960mm
Module Pixel(dots)
32dots*16dots
Brightness
≥5500cd/square meter
Screen viewing angle
≥ 160 degrees
Maximum starting power
≤ 1000W/㎡
Average power consumption
≤ 120W/㎡
Frame switching frequency
≥ 60 frames/second
Refresh frame frequency
1920Hz-3840Hz
Power
110V/220V±15% 50Hz/60Hz
Operating humidity
10%-65%RH
Working temperature range
-20-40 ℃
Control method
computer control

Product Uses

Widely used in advertising of shopping malls, shopping centers, outdoor cinemas, entertainment venues, etc.
