Product Description
Outdoor P2.604 rental led display is a special LED display used for stage performances and cultural activities. Generally appeared by the rental form, so named LED rental screen. They have certain functions of windproof, rainproof and waterproof.
Product Advantage
1. Small error, zero splicing: full color led display traditional cabinet due to the use of sheet metal processing means, such processing process itself error, plus easy to deform after processing, so the error in millimeters, it is difficult to achieve the display on the zero splicing requirements. LED display leasing aluminum cabinet as a result of the use of molded into a combination of shaping and machining of the production process, can be controlled to error in one-tenth of a millimeter, it can be Zero splicing requirements.
2. Fast installation: due to the cabinet for the aluminum structure, lighter weight, higher precision, easy and fast disassembly, technicians can be within a few minutes of a single box splicing, greatly reducing the installation and disassembly time, saving labor costs and expenses.
3. Light weight, thin structure: rental led display panel light weight, thin structure, with lifting and quick installation function, so as to comply with the requirements of the rental occasions such as rapid installation, dismantling and transportation requirements. Easy to load and unload, release easy to operate, the whole screen loading and unloading by fast bolts to fix and connect, can be accurate and fast frame screen and dismantle the screen, and can be put together in different shapes to meet the requirements of the scene.
4. Unique technology: unique welding process optimized structural design, to avoid frequent handling of electronic products caused by poor contact with the solder joints resulting in failure and other conditions.
Technical Parameters
Pitch Size | 2.604mm |
Module Size | 250*250mm |
Module Pixel(dots) | 96dots*96dots |
Pixel Configuration | 1 Red, 1 Green, 1 Blue SMD 3-in-1 |
Color scale | 65536degree/16777216colors |
Pixel density | 147456pixels/square meter |
View angle(H/V) | ≥140/140degree |
Brightness | ≥5500cd/square meter |
Brightness adjustment | 64 level automatic or manual |
View distance | 3--200m |
Power consumption | 100-1200W/square meter |
Net weight | 30kg/square meter |
Operating temperature | —25°C~+60C |
Operating humidity | 10%—95%RH |
Out of control dot | ≤1/10,000 |
Whole Display Flatness | ≤1mm Juncture |
Exchange frame speed | >150frames per second |
Refresh frame frequency | 1920Hz-3840Hz |
Control distance | 120m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
Power | 110V/220V±15% 50160Hz |
Operating system | Windows series |
Drive mode | constant current driving, 1/21 scan |
Display mode | VGA640X480—VGA1600X1024 |
Protection Level | IP65 |
Maintenance way | Rear access |
Accepting signal | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
Product Uses
The P2.604 event led screen in the field of major applications more and more play an important role, after all, it can be real-time, synchronous, clear information dissemination way to play a variety of information, its color fidelity, adaptability. The exterior led display common application scenarios are as follows:
1. Stage performances in the field: all kinds of concerts, cultural evenings, opening ceremonies and other activities.
2. Automobile car show field.
3. The field of television broadcasting: television studios and television broadcasting and other large-scale activities.
In addition to the above, the large led display can also be widely used in hotels, schools, singing and dancing activities party, all kinds of conferences, exhibitions, stadiums, theaters, auditoriums, lecture halls, multi-purpose halls, meeting rooms, interpretation halls, discos, nightclubs, high-end entertainment discos, TV spring gala, important cultural activities in provinces and cities, and other places.
